viernes, 27 de marzo de 2009

Accidentes: 32 años de Tenerife

Hoy hace 32 años de aquel día trágico, en el aeropuerto de la isla Española de Tenerife dos B747 chocaron en pista.





Tenerife está plagada de niebla. Las nubes se acumulan alrededor del extinto volcán Pico de Teide y esparcen una repentina bruma extraña a través de la isla de vacaciones del Atlántico. El domingo 27 de marzo de 1977 estaba muy nublado.

Una bomba, instalada por terroristas del movimiento de liberación de las islas Canarias, había explotado en una tienda del aeropuerto de Las Palmas, en la vecina isla de Gran Canaria, y las aeronaves estaban siendo desviadas de las Palmas a Santa Cruz. Entre ellas había dos jumbo jets Boeing 747: el vuelo 4805 de la línea holandesa KLM, proveniente de Amsterdam, y el vuelo 1736 de Pan Am, proveniente de Los Ángeles y Nueva York.

Los tres controladores aéreos de servicio en la torre de control tenían once aeronaves en tierra, todas esperando autorización para despegar. Pero sus principales preocupaciones eran la niebla que espesaba rápida mente y había reducido la visibilidad a 500 metros, y las luces del eje de pista que no estaban funcionando. Para aumentar la confusión, dos de las tres frecuencias de radio del aeropuerto estaban fuera de acción y los pilotos tenían que hablar a los controladores por el parloteo de la única frecuencia que quedaba. La escena estaba lista para el desastre.



Un diagrama que muestra la orientación de las pistas y calles de rodaje en el aeropuerto de Los Rodeos, Tenerife, así como la ubicación de los desechos sobre el terreno después del accidente

Esta es la transcripción del data recorder

Legenda:
APP = Tenerife tower
RDO-2 = Pan Am Radio communications (co-pilot)
CAM-1 = Cockpit Area Mike PanAm (captain)
CAM-2 = Cockpit Area Mike PanAm (co-pilot)
CAM-3 = Cockpit Area Mike PanAm (flight engineer)
KLM = KLM Radio Communications
KLM-1 = KLM Cockpit Area Mike (captain)
KLM-2 = KLM Cockpit Area Mike (co-pilot)
KLM-3 = KLM Cockpit Area Mike (flight engineer)

Time: Source: Content:
1701:57.0 RDO-2 Tenerife the Clipper one seven three six. (1702:00.2)
1702:01.8 APP Clipper one seven three six Tenerife.
1702:03.6 RDO-2 Ah- We were instructed to contact you and also to taxi down the runway, is that correct? (1702:07.4)
1702:08.4 APP Affirmative, taxi into the runway and -ah leave the runway third, third to your left, (background conversation in the tower).
1702:16.4 RDO-2 Third to the left, O.K. (17:02.18.3)
1702:18.4 CAM-3 Third he said.

CAM-? Three.
1702:20.6 APP -ird one to your left.
1702:21.9 CAM-1 I think he said first.
1702:26.4 CAM-2 I'll ask him again.

CAM-? * * *
1702:32.2 CAM-2 Left turn.
1702:33.1 CAM-1 I don't think they have take-off minimums anywhere right now.
1702:39.2 CAM-1 What really happened over there today?
1702:41.6 CAM-4 They put a bomb (in) the terminal, Sir, right where the check-in counters are.
1702:46.6 CAM-1 Well we asked them if we could hold and -uh- I guess you got the word, we landed here **

CAM-? * * *
1702:49.8 APP KLMfour eight zero five how many taxiway -ah- did you pass?
1702:55.6 KLM I think we just passed charlie four now.
1702:59.9 APP O.K. ... at the end of the runway make one eighty and report -ah- ready -ah- for ATC clearance (background conversation in the tower).
1703:09.3 CAM-2 The first one is a ninety degree turn.
1703:11.0 CAM-1 Yeah, O.K.
1703:12.1 CAM-2 Must be the third ... I'll ask him again.
1703:14.2 CAM-1 O.K.
1703:16.6 CAM-1 We could probably go in it's ah ...
1703:19.1 CAM-1 You gotta make a ninety degree turn.
1703:21.6 CAM-1 Yeah, uh.
1703:21.6 CAM-2 Ninety degree turn to get around this ... this one down here it's a forty five.
1703:29.3 RDO-2 Would you confirm that you want the clipper one seven three six to turn left at the third intersection? (1703:35.4).
1703:35.1 CAM-1 One, two.
1703:36.4 APP The third one, sir, one; two, three, third, third one (1703:38.3)..
1703:38.3 CAM-? One two (four).
1703:39.0 CAM-1 Good.
1703:40.1 CAM-1 That's what we need right, the third one.
1703:42.9 CAM-3 Uno, dos, tres.
1703:44.0 CAM-1 Uno, dos, tres.
1703:44.9 CAM-3 Tres - uh - si.
1703:46.5 CAM-1 Right.
1703:47.6 CAM-3 We'll make it yet.
1703:47.6 APP ...er seven one three six report leaving the runway.
1703:49.1 CAM-2 Wing flaps?
1703:50.2 CAM-1 Ten, indicate ten, leading edge lights are green.
1703:54.1 CAM-? Get that.
1703:55.0 RDO-2 Clipper one seven three six (1703:56.4)
1703:56.5 CAM-2 Yaw damp and instrument?
1703:58.6 CAM-1 Ah- Bob we'll get a left one *
1703:59.3 CAM-2 I got a left.
1704:00.6 CAM-1 Did you?
1704.00.9 CAM-2 And -ah- need a right.
1704:02.6 CAM-1 I'll give you a little *
1704:03.8 CAM-2 Put a little aileron in this thing.
1704:05.0 CAM-1 O.K., here's a left and I'll give you a right one right here.
1704:09.7 CAM-1 O.K. right turn right and left yaw.
1704:11.4 CAM-2 Left yaw checks.
1704:12.4 CAM-1 O.K., here's the rudders.
1704:13.6 CAM-1 Here's two left, centre, two right centre.
1704:17.8 CAM-2 Checks.
1704:19.2 CAM-2 Controls.
1704:19.6 CAM-1 Haven't seen any yet!
1704:20.3 CAM-2 I haven't either.
1704:21. 7 CAM-1 They're free, the indicators are checked.
1704:24.6 CAM-2 There's one.
1704:25.8 CAM-1 There's one.
1704:26.4 CAM-1 That's the ninety degree.
1704:28.5 CAM-? O.K.
1704:34.5 CAM-? ***

CAM-2 Weight and balance finals?
1704:37.7 CAM (Sounds similar to stabilizer trim).(1704:44.8)
1704:37.2 CAM-1 We were gonna put that on four and a half
1704:39.8 CAM-3 We got four and a half and we weigh five thirty four (sound of stabilizer trim).
1704:44.6 CAM-2 Four and a half on the right.
1704:46.8 CAM-2 Engineer's taxi check.
1704:48.4 CAM-3 Taxi check is complete.
1704:50.5 CAM-2 Take-off and departure briefing?
1704:52.1 CAM-1 O.K., it'll be standard, we gonna go straight out there till we get thirty five hundred feet then we're gonna make that reversal and go back' out to * fourteen.
1704:58.2 APP -m eight seven zero five and clipper one seven ... three six, for your information, the centre line lighting is out of service. (APP transmission is readable but slightly broken.)
1705:05.8 KLM I copied that.
1705:07.7 RDO-2 Clipper one seven three six.
1705:09.6 CAM-1 We got centre line markings (* only) (could be "don't we) they count the same thing as ... we need eight hundred metres if you don't have that centre line... I read that on the back (of this) just a while ago.
1705:22.0 CAM-1 That's two.
1705:23.5 CAM-3 Yeh, that's forty-five there.
1705:25.7 CAM-1 Yeh.
1705:26.5 CAM-2 That's this one right here.
1705:27.2 CAM-1 (Yeh)I know.
1705:28.1 CAM-3 O.K.
1705:28.5 CAM-3 Next one is almost a forty-five, huh yeh.
1705:30.6 CAM-1 But it goes...
1705:32.4 CAM-1 Yeh, but it goes ... ahead, I think (it's) gonna put us on (the) taxiway.
1705:35.9 CAM-3 Yeah, just a little bit yeh.
1705:39.8 CAM-? O.K., for sure.
1705:40.0 CAM-2 Maybe he, maybe he counts these (are) three.

CAM-? Huh.
1705:44.8 CAM-? I like this.
1705:44.8 KLM Uh, the KLM ... four eight zero five is now ready for take-off ... uh and we're waiting for our ATC clearance.
1705:53.4 APP KLM eight seven * zero five uh you are cleared to the Papa Beacon climb to and maintain flight level nine zero right turn after take-off proceed with heading zero four zero until intercepting the three two five radial from Las Palmas VOR. (1706:08.2)
1706:09.6 KLM Ah roger, sir, we're cleared to the Papa Beacon flight level nine zero, right turn out zero four zero until intercepting the three two five and we're now (at take-off). (1706:17.9)
ca. 1706:13 KLM-1 We gaan. (We're going)
1706:18.19 APP OK.
1706:19.3 RDO No .. eh.
1706:20.08 APP Stand by for take-off, I will call you.
1706:20.3 RDO And we're still taxiing down the runway, the clipper one seven three six.
1706:19.39 - 1706:23.19
RDO and APP communications caused a shrill noise in KLM cockpit - messages not heard by KLM crew.
1706:25.6 APP Roger alpha one seven three six report when runway clear
1706:29.6 RDO OK, we'll report when we're clear.

APP Thank you
1706:32.43 KLM-3 Is hij er niet af dan? {Is he not clear then?}
1706:34.1 KLM-1 Wat zeg je? {What do you say?}
1706:34.15 KLM-? Yup.
1706:34.7 KLM-3 Is hij er niet af, die Pan American? {Is he not clear that Pan American?}
1706:35.7 KLM-1 Jawel. {Oh yes. - emphatic}
1706:40
PanAm captain sees landinglights of KLM Boeing at approx. 700m
1706:44
PH-BUF started rotation
1706:47.44 KLM-1 [Scream]
1706:50


collision



Foto minutos antes del accidente

Fuentes:
AirDisaster.com
1001 Crash
Tragedias y accidentes en el siglo XX
Cockpit Voice Recorder Database
